Technical Specifications

Here are the key specifications for this product model. Want to know more about this equipment? Download the brochure or contact us.

PERFORMANCE

Straight Tipping Load 24,960 lbs (11320 kg)
Bucket Breakout 28,430 lbf (126.4 kN)
Straight Tipping Load - Deflection -
Full Turn Tipping Load - Deflection -
Breakout - Bucket 28,430 lbf (12895.63 kgf)
Breakout - Bucket 28,430 lbf (12895.63 kgf)
Full Turn Tipping Load 21,290 lbs (9650 kg)
Load Sensing Yes
Ride Control System Yes
Oscillation - Rear Axle 26

CAPACITIES

Heaped Capacity 4 yd³ (2.8 m³)
Fuel Tank 59 gallons (US) (222 ltr)

DRIVELINE

Engine Output - Gross 184 hp (137 kW)
Tire size - Standard 21 R25
Generator - Type -
Emissions Technology Cooled Exhaust Gas Recirculation
After Treatment System Selective Catalytic Reduction
Inverter - Type -
Torque 689 lbf / ft (934 Nm)
Engine Output - Net 184 hp (137 kW)
Hydrostatic Brake - Actuation -
Displacement 348 Inches³ (5.7 ltr)
Brake Resistor -
Service Brake - Location Axle Outboard
Engine Model D6J
Tyre - Model XHA 2
Tire - Model XHA 2
Aspiration Turbo. aftercooled
Traction Control Yes
Motor - Type -
Transmission Model HTE 125 C
Transmission Manufacturer Volvo
Transmission Manufacturer Volvo
Engine Manufacturer Volvo
Engine Manufacturer Volvo
Transmission Type Powershift
Emission Rating Tier 4 / Stage IV
Tire - Manufacturer Michelin
Service Brake - Type Wet Disc
Hydrostatic System Braking -
Rated Speed 1,400

WEIGHTS

Operating Weight 34,350 lbs (15580 kg)

DIMENSIONS

Full Lift Reach 3 ft 6 in ft/in (1070 mm)
Height - Maximum 19 ft 2 in ft/in (5840 mm)
Ground clearance 18 inches (450 mm)
Dig Depth 4 inches (112 mm)
Dump Angle - At Dump 45
Loader - Arm Type Double Arm
Turn radius over bucket - std. 19 ft 10 in ft/in (6050 mm)
Dump Angle - Maximum 45
Wheelbase 10 ft ft/in (3050 mm)
Height - Over Cab 10 ft 9 in ft/in (3280 mm)
Width Over tires - Std 8 ft 2 in ft/in (2490 mm)
Length with bucket on ground 25 ft 3 in ft/in (7690 mm)
Full Lift Dump Height 9 ft 4 in ft/in (2830 mm)
Height - Pivot Pin 13 ft 3 in ft/in (4040 mm)
Bucket Type GP w/Bolt-On Edge - Hook On
Bucket Width 9 ft ft/in (2750 mm)
Loader - Geometry Torque Parallel
Full Lift Dump Height - Maximum 9 ft 7 in ft/in (2910 mm)
