Technical Specifications

Here are the key specifications for this product model. Want to know more about this equipment? Download the brochure or contact us.

PERFORMANCE

Straight Tipping Load 20,520 lbs (9310 kg)
Bucket Breakout 19,060 lbf (84.8 kN)
Straight Tipping Load - Deflection -
Full Turn Tipping Load - Deflection -
Breakout - Bucket 19,060 lbf (8645.47 kgf)
Breakout - Bucket 19,060 lbf (8645.47 kgf)
Full Turn Tipping Load 17,770 lbs (8060 kg)
Load Sensing Yes
Ride Control System Yes
Oscillation - Rear Axle 26

CAPACITIES

Heaped Capacity 3 yd³ (2.1 m³)
Fuel Tank 59 gallons (US) (222 ltr)

DRIVELINE

Engine Output - Gross 164 hp (122 kW)
Tire size - Standard 21 R25
Generator - Type -
Emissions Technology Exhaust Gas Recirculation - Cooled
After Treatment System Selective Catalytic Reduction
Inverter - Type -
Torque 605 lbf / ft (820 Nm)
Engine Output - Net 164 hp (122 kW)
Hydrostatic Brake - Actuation -
Displacement 348 Inches³ (5.7 ltr)
Brake Resistor -
Service Brake - Location Axle Outboard
Engine Model D6J
Tyre - Model XHA 2
Tire - Model XHA 2
Aspiration Turbo. aftercooled
Traction Control Yes
Motor - Type -
Transmission Model HTE 125 C
Transmission Manufacturer Volvo
Transmission Manufacturer Volvo
Engine Manufacturer Volvo
Engine Manufacturer Volvo
Transmission Type Powershift
Emission Rating Tier 4 / Stage IV
Tire - Manufacturer Michelin
Service Brake - Type Wet Disc
Hydrostatic System Braking -
Rated Speed 1,500

WEIGHTS

Operating Weight 26,620 lbs (12070 kg)

DIMENSIONS

Full Lift Reach 3 ft 3 in ft/in (1000 mm)
Height - Maximum 16 ft 10 in ft/in (5120 mm)
Ground clearance 17 inches (440 mm)
Dig Depth 5 inches (123 mm)
Dump Angle - At Dump 45
Loader - Arm Type Double Arm
Turn radius over bucket - std. 19 ft ft/in (5790 mm)
Dump Angle - Maximum 45
Wheelbase 9 ft 10 in ft/in (3000 mm)
Height - Over Cab 10 ft 9 in ft/in (3270 mm)
Width Over tires - Std 8 ft ft/in (2430 mm)
Length with bucket on ground 23 ft 10 in ft/in (7270 mm)
Full Lift Dump Height 9 ft 4 in ft/in (2850 mm)
Height - Pivot Pin 12 ft 8 in ft/in (3870 mm)
Bucket Type GP w/Bolt-On Edge - Pin On
Bucket Width 8 ft 2 in ft/in (2500 mm)
Loader - Geometry Torque Parallel
Full Lift Dump Height - Maximum 9 ft 4 in ft/in (2850 mm)
