Wheel Loaders
Volvo L30G
Experience superior performance in the robust Volvo L30G. Built to work hard, the versatile L30G is packed with safety and performance-enhancing features including high quality attachments, comfortable cab, state-of-the-art hydraulics, easy-to-use controls and superb serviceability. Operate with confidence and control in the durably designed L30G compact wheel loader.
Features and Benefits
Volvo L30G Wheel Loader - BORN TO PERFORM
Comfortable cab
Excellent hydraulics
Easy-to-use controls
Outstanding serviceability
Wide range of attachments
Lifetime Frame & Structure Guarantee Frame (Articulation Joint, Loader Arm)
Technical Specifications
Here are the key specifications for this product model. Want to know more about this equipment? Download the brochure or contact us.
PERFORMANCE
| Straight Tipping Load | 9,590 lbs (4350 kg) |
| Bucket Breakout | 13,713 lbf (61 kN) |
| Straight Tipping Load - Deflection | - |
| Full Turn Tipping Load - Deflection | - |
| Breakout - Bucket | 13,713 lbf (6220.1 kgf) |
| Breakout - Bucket | 13,713 lbf (6220.1 kgf) |
| Full Turn Tipping Load | 8,488 lbs (3850 kg) |
| Load Sensing | No |
| Ride Control System | No |
| Oscillation - Rear Axle | - |
CAPACITIES
| Heaped Capacity | 1 yd³ (1 m³) |
| Fuel Tank | 22 gallons (US) (84 ltr) |
DRIVELINE
| Engine Output - Gross | 74 hp (55.4 kW) |
| Tire size - Standard | 365 / 80 R20 |
| Generator - Type | - |
| Emissions Technology | Exhaust Gas Recirculation - Cooled |
| After Treatment System | Diesel Particulate Filter |
| Inverter - Type | - |
| Torque | 195 lbf / ft (265 Nm) |
| Engine Output - Net | - |
| Hydrostatic Brake - Actuation | All Wheels |
| Displacement | 203 Inches³ (3.3 ltr) |
| Brake Resistor | - |
| Service Brake - Location | Driveline |
| Engine Model | D3.3H |
| Tyre - Model | - |
| Tire - Model | - |
| Aspiration | Turbo |
| Traction Control | No |
| Motor - Type | - |
| Transmission Model | - |
| Transmission Manufacturer | Volvo |
| Transmission Manufacturer | Volvo |
| Engine Manufacturer | Volvo |
| Engine Manufacturer | Volvo |
| Transmission Type | Hydrostatic |
| Emission Rating | Tier 4 |
| Tire - Manufacturer | - |
| Service Brake - Type | Disc |
| Hydrostatic System Braking | Yes |
| Rated Speed | 2,600 |
WEIGHTS
| Operating Weight | 12,125 lbs (5500 kg) |
DIMENSIONS
| Full Lift Reach | 2 ft 3 in ft/in (680 mm) |
| Height - Maximum | 14 ft 6 in ft/in (4420 mm) |
| Ground clearance | 24 inches (600 mm) |
| Dig Depth | 2 inches (50 mm) |
| Dump Angle - At Dump | 45 |
| Loader - Arm Type | Double Arm |
| Turn radius over bucket - std. | 13 ft 11 in ft/in (4245 mm) |
| Dump Angle - Maximum | 45 |
| Wheelbase | 7 ft 1 in ft/in (2150 mm) |
| Height - Over Cab | 9 ft ft/in (2740 mm) |
| Width Over tires - Std | 6 ft ft/in (1835 mm) |
| Length with bucket on ground | 17 ft 4 in ft/in (5280 mm) |
| Full Lift Dump Height | 8 ft 6 in ft/in (2580 mm) |
| Height - Pivot Pin | 10 ft 8 in ft/in (3260 mm) |
| Bucket Type | GP w/Teeth - Quickhitch |
| Bucket Width | 6 ft 3 in ft/in (1900 mm) |
| Loader - Geometry | Z-Bar |
| Full Lift Dump Height - Maximum | 8 ft 6 in ft/in (2580 mm) |
