Wheel Loaders
Volvo L120 Electric
A valuable asset for customers looking to maintain maximum efficiency with minimal environmental impact. Reduced maintenance and quiet operation make this 20-tonne electric wheel loader with a 6-tonne payload capacity the perfect partner across a range of applications.
Matching the powerful performance of its diesel equivalent, the L120 Electric is a 20-tonne
wheel loader with the added benefit of zero exhaust emissions and a near silent operation.
Thanks to a payload capacity of 6 tonnes, it can meet the demands of a range of tasks across segments such as urban infrastructure maintenance, waste and recycling, agriculture, forestry, and ports and logistics centres. What is more, it offers a lower operating cost with an energy cost reduction compared to a diesel driveline. With no engine-related parts, it also ensures 30% reduced maintenance requirements and increased uptime to improve your productivity.
Downloads
Features and Benefits
Volvo L120 Electric Wheel Loader -
- Deliver a full work shift of around 5-9 hours of runtime, depending on the environment, across most light and medium duty applications – or operate 2 shifts with charging during breaks
- Enables charging from 10% to 95% in just 1 hour and 30 minutes, while a 40 kW DC charger provides a complete charge from empty to full in 7 hours for convenient overnight charging
- The PU500 Mobile Power Unit, available to help fully charge in one hour 30 minutes
- The My Equipment digital tool, ensuring your machine is ready for action with valuable insights into battery status, machine hours and geographic location
Technical Specifications
Here are the key specifications for this product model. Want to know more about this equipment? Download the brochure or contact us.
Driveline
| Transmission Type | Automatic Power Shift |
| Motor - Type | Permanent Magnet Synchronous Motor |
| Tire Manufacturer | Bridgestone |
| Tire Size | 24 R25 |
| Tire Model | VJT |
| Service Brake - Type | Wet Disc |
| Battery Capacity | 282 kWh |
| Rated Output | 310 hp (228 kW) |
Dimensions
| Wheelbase | 10 ft 6 in (3200 mm) |
| Length With Bucket On Ground | 27 ft 8 in (8430 mm) |
| Height - Over Cab | 11 ft 1 in (3380 mm) |
| Ground Clearance | 17 inches (430 mm) |
| Width Over Tires - Std | 8 ft 10 in (2680 mm) |
| Bucket Type | GP w/Bolt-on Edge |
| Bucket Width | 9 ft 10 in (3000 mm) |
| Full Lift Dump Height | 9 ft 5 in (2870 mm) |
| Full Lift Reach | 4 ft (1220 mm) |
| Loader - Geometry | Torque Parallel |
| Dump Angle - At Dump | 45 ° |
| Dump Angle - Maximum | 50 ° |
| Height - Pivot Pin | 13 ft 5 in (4090 mm) |
| Height - Maximum | 18 ft 3 in (5560 mm) |
| Turn Radius Over Bucket - Std. | 21 ft 4 in (6505 mm) |
Capacities
| Heaped Capactiy | 5 yd³ (3.6 m³) |
| Smallest Bucket Capacity | 4 yd³ (3.3 m³) |
| Largest Bucket Capacity | 7 yd³ (5.5 m³) |
Performance
| Straight Tipping Load | 32,805 lbs (14880 kg) |
| Full Turn Tipping Load | 28,065 lbs (12730 kg) |
| Bucket Breakout | 38,218 lbf (170 kN) |
| Ride Control System | No |
| Oscillation - Rear Axle | 26 ° |
| Load Sensing | Yes |
Weights
| Bucket Capacity | 4.3-7.2 yd³ (3.3-5.5 m³) |
| Operating Weight | 43,387 lbs (19680 kg) |
