Volvo ECR18E
The ECR18E short-swing compact excavator is a 1.8 ton class machine that can squeeze into the tightest of spaces, and thanks to its ultra-short tail design – the shortest radius in the Volvo range – it can work close to obstacles and fit in spaces as narrow as 39 inches.
Features and Benefits
Volvo ECR18E Excavator - SHORT SWING, BIG PERFORMANCE
Lifetime Frame & Structure Guarantee (Frame, Boom & Arm)
Technical Specifications
Here are the key specifications for this product model. Want to know more about this equipment? Download the brochure or contact us.
DRIVELINE
| Engine Output - Gross | 16 hp (12 kW) |
| Track Shoe Width | 9 inches (230 mm) |
| Engine Manufacturer | Volvo |
| Engine Manufacturer | Volvo |
| Engine Output - Net | 16 hp (12 kW) |
| Number Of Track Rollers - Each Side | 3 |
| Emission Rating | - |
| Rated speed | 2,300 |
| Engine Model | D 0.9A |
| Displacement | 55 Inches³ (0.898 ltr) |
| Aspiration | Naturally Aspirated |
DIMENSIONS
| Heaped Bucket Capacity - Standard | 0 yd³ (0.036 m³) |
| Track Gauge - Standard | - |
| Vertical Wall - Mono Boom | 6 ft 3 in ft/in (1898 mm) |
| Dig Height - Mono Boom | 11 ft 4 in ft/in (3442 mm) |
| Dump Height - Mono Boom | 8 ft ft/in (2444 mm) |
| Digging Reach - Mono Boom | - |
| Width over fixed tracks | 4 ft 5 in ft/in (1352 mm) |
| Transport Length Mono Boom | 12 ft 11 in ft/in (3932 mm) |
| Transport Height - Maximum | 7 ft 6 in ft/in (2298 mm) |
| Dig Depth - Mono Boom | 7 ft 4 in ft/in (2234 mm) |
| Overall Undercarriage Width | 3 ft 3 in ft/in (995 mm) |
| Ground Level Reach - Mono Boom | 12 ft 10 in ft/in (3921 mm) |
| Bucket Weight - Standard | 73 lbs (33 kg) |
| Ground Clearance | 18 inches (456 mm) |
| Track Length On Ground | 5 ft 4 in ft/in (1620 mm) |
| Overall Bucket Width - Standard | 18 inches (450 mm) |
| Zero Tailswing? | Yes |
| Zero Tailswing | Yes |
| Longest Dipper | 3 ft 9 in ft/in (1150 mm) |
| Standard Dipper | 3 ft 1 in ft/in (950 mm) |
| Mono Boom - Size | - |
| Capacity Standard | - |
WEIGHTS
| Operating Weight | 3,748 lbs (1700 kg) |
HYBRID SYSTEM UNIT
| Type | - |
| Rated Power Output | - |
PERFORMANCE
| Side lift - Max Reach | 463 lbs (210 kg) |
| Boom Pressure | 2,466 PSI (170 bar) |
| Standard Shoe Width | 9 inches (230 mm) |
| Ground Bearing Pressure | 4 PSI (28.4 kPa) |
| End lift - Max Reach | 547 * lbs (248 * kg) |
| Bucket Breakout | 2,900 lbf (12.9 kN) |
| Total Flow | 9 gallons (US) / min (34 lt/min) |
| Main Pump | Gear |
| Dipper Tearout | 1,787 lbf (7.95 kN) |
CAPACITIES
| Fuel Tank | 6 gallons (US) (21 ltr) |
| Hydraulic Tank | 4 gallons (US) (15 ltr) |
DESCRIPTION
| Telematics Available | - |
| Dipper Length - Standard | 3 ft 1 in ft/in (950 mm) |
