Compactors
Volvo DD140C
The Volvo DD140C asphalt roller delivers maximum efficiency and a powerful performance. With an industry-leading water system, the asphalt roller delivers straightforward operation and compaction at its best. Benefit from optimum power and high density levels with Volvo compaction equipment.
Downloads
Features and Benefits
Volvo DD140C Compactor - THE ULTIMATE COMPACTION MACHINE
Volvo D13J Tier 4 Final engine with up to 20% fuel improvements over B-series (with auto idle and eco-mode)
New Volvo common side console and display 8-amplitude option
Auto-reversing eccentrics (8 amplitude version)
Industry-leading automatic drum wetting system with full duplicate back up spray bars on both drums
Technical Specifications
Here are the key specifications for this product model. Want to know more about this equipment? Download the brochure or contact us.
DRIVELINE
| Engine Output | 148 hp (110 kW) |
| Emission Rating | - |
| Diesel Particulate Filter | Yes |
| Diesel Oxidation Catalyst | - |
| Selective Catalytic Reduction | Yes |
| Exhaust Gas Recirculation | Yes |
| Specific Fuel Consumption @ Rated Power | - |
| Displacement | - |
| Engine model | D4 |
| Rated Speed | 2,200 |
| Transmission | Hydrostatic |
| Engine manufacturer | Volvo |
| Engine manufacturer | Volvo |
DIMENSIONS
| Drum Width - Front | 84 inches (2135 mm) |
| Overall Length | 235 inches (5973 mm) |
| Overall Width | 93 inches (2350 mm) |
| Drum Diameter - Front | 55 inches (1400 mm) |
| Turning Radius - Inside | 180 inches (4562 mm) |
| Wheelbase | 140 inches (3550 mm) |
| Turning Radius - Outside | - |
| Drum Diameter - Rear | 55 inches (1400 mm) |
| Drum Width - Rear | 84 inches (2135 mm) |
| Ground Clearance | 20 inches (505 mm) |
| Rolling Width | 84 inches (2135 mm) |
| Height - With ROPS | 125 inches (3177 mm) |
| Drum Shell Thickness | 1 inches (20 mm) |
| Height - Without ROPS | - |
PERFORMANCE
| Amplitude stage 8 - rear | - |
| Centrifugal force 8 - rear | - |
| Travel Speed 3 | - |
| Centrifugal force 7 - rear | - |
| Travel Speed 5 | - |
| Drum Oscillation | - |
| Amplitude stage 7 - rear | - |
| Max. Travel Speed | 8 mph (12.2 kph) |
| Centrifugal force 6 - rear | - |
| Amplitude stage 8 - front | - |
| Drive To Drums | Both |
| Linear Drum Load - Front | - |
| Amplitude stage 7 - front | - |
| Amplitude stage 6 - rear | - |
| Amplitude stage 1 - front | 0 inches (0.88 mm) |
| Centrifugal force 6 - front | - |
| Amplitude stage 6 - front | - |
| Travel Speed 1 | 5 mph (7.8 kph) |
| Travel Speed 2 | 8 mph (12.2 kph) |
| Frequency - stage 1 - front | 45 |
| Travel Speed 6 | - |
| Travel Speed 4 | - |
| Centrifugal force 8 - front | - |
| Linear Drum Load - Rear | - |
| Number of Frequency/Amplitude Settings | 2 / 8 |
| Centrifugal force 7 - front | - |
WEIGHTS
| Operating Weight | 30,486 lbs (13828 kg) |
| Weight - Rear | 14,330 lbs (6500 kg) |
| Weight - Front | 16,156 lbs (7328 kg) |
CAPACITIES
| Tank Capacity For Drum | 338 gallons (US) (1280 ltr) |
| DEF Tank | 5 gallons (US) (20 ltr) |
| Fuel Tank | 58 gallons (US) (219.9 ltr) |
DESCRIPTION
| Platform | CareTrack |
| Telematics Available | Yes |
