Cone Crushers

Sandvik QS332

  • 36"
  • 379
  • 79,366

Sandvik QS332 is a compact, robust mobile secondary cone crushing solution designed for versatility and ease of operation. Fitted with Sandvik CS430 “S” type gyratory cone crusher, it is capable of accepting large feed sizes whilst achieving high production capacities.

Technical Specifications

Here are the key specifications for this product model. Want to know more about this equipment? Download the brochure or contact us.

Technical Data

Equipment Sandvik CS430 cone crusher
Maximum feed size 360 mm (14 ⅛ in.)
Capacity (up to) 344 mtph (379 stph)
Engine C9 / C9.3 Acert 261 kW (350 hp)
Transport length 16 m (51 ft 10 in.)
Transport width 3 m (9 ft 2 ¼ in.)
Transport height 4 m (12 ft 5 in.)
Weight 41,831 kg (92,221 lb)
Transport length with HS 19 m (63 ft 7 in.)
Transport width with HS 4 m (11 ft 5 in.)
Transport height with HS 4 m (12 ft 5 in.)
Weight with HS 52,000 kg (115,742 lb)
